Lankhorst Mouldings
Lankhorst Mouldings produces a wide range of both single and multi-layer coil storage systems, that will improve the safety of your coil storage warehouse tremendously. Among others, our product range includes coil pads, coil saddles, coil blocks, coil mats, coil cradles, coil wedges and the turn-key KLP® Roll Stop System.
More info:
Brochures:
- General brochure "Coil storage systems
- KLP® RollStop System
- KLP® Rollblocks
- KLP® RollCradle System
- KLP® Storageblocks
- KLP® CoilWedge System
- KLP® Coilcarriers & Slitcoilcarriers
- KLP® Storagebeams & Coilwedges
- KLP® PipeStop System
- KLP® Coil Carrier Connect
For further information visit the Lankhorst website
Sort by
Display per page
Lankhorst RollStop RS40
252551
Diameter coils: 564-2500 mm
Coil width: 610-1910 mm (using spacers)
Max load (using 4 RollStops): 40 tons
Temperatures up to 60 °C
For stacking up to 3 levels
To be used together with Rail RS40 or Rail RS40 WR
Coil width: 610-1910 mm (using spacers)
Max load (using 4 RollStops): 40 tons
Temperatures up to 60 °C
For stacking up to 3 levels
To be used together with Rail RS40 or Rail RS40 WR
Lankhorst RollStop RS40 HR
252557
Heat resistant version, for temperatures up to 110°C
Diameter coils: 564-2500 mm
Coil width: 610-1910 mm (using spacers)
Max load (using 4 RollStops): 40 tons
Temperatures up to 110 °C
For stacking up to 3 levels
To be used together with Rail RS40 or Rail RS40 WR
Diameter coils: 564-2500 mm
Coil width: 610-1910 mm (using spacers)
Max load (using 4 RollStops): 40 tons
Temperatures up to 110 °C
For stacking up to 3 levels
To be used together with Rail RS40 or Rail RS40 WR
Lankhorst Rail RS40
252552
To be used togehter with the RollStop RS40, CoilWedge 120/34 or 150/34 or RollCradle system
1 pc rail =4 meters
Also available in Weather resistant version (Lankhorst Rail RS40 Outdoor (WR)
To create lengths over 4 meters, the Steel Connector RS40 must be used
1 pc rail =4 meters
Also available in Weather resistant version (Lankhorst Rail RS40 Outdoor (WR)
To create lengths over 4 meters, the Steel Connector RS40 must be used
Lankhorst Rail RS40 Outdoor (WR)
252558
Weather resistant version for outdoor use
To be used togehter with the RollStop RS40, CoilWedge 120/34 or 150/34 or RollCradle system
1 pc rail =4 meters
To create lengths over 4 meters, the Steel Connector RS40 Outdoor (WR) must be used
To be used togehter with the RollStop RS40, CoilWedge 120/34 or 150/34 or RollCradle system
1 pc rail =4 meters
To create lengths over 4 meters, the Steel Connector RS40 Outdoor (WR) must be used
Lankhorst Steel Connector RS40
252553
Links the rail sections to create sections longer then 4 meters
To tighten the Steel Connector an Installation Tool RS40 is needed
To tighten the Steel Connector an Installation Tool RS40 is needed
Lankhorst Steel Connector RS40 Outdoor (WR)
252559
Weather resistant version for outdoor use
Links the rail sections to create sections longer then 4 meters
To tighten the Steel Connector an Installation Tool RS40 is needed
Links the rail sections to create sections longer then 4 meters
To tighten the Steel Connector an Installation Tool RS40 is needed
Lankhorst Rail Spacer RS40
252554
Used together (in pair) with Tunnel spacer RS40 to fixate the parallell rail pieces at a correct distance from each other, depending on coil width
One pc per 4 meters is needed for lenghts over 4 meters
For Rail RS40 and Rail RS40 Outdoor (WR)
One pc per 4 meters is needed for lenghts over 4 meters
For Rail RS40 and Rail RS40 Outdoor (WR)
Lankhorst Tunnel Spacer RS40
252555
Used together (in pair) with Rail spacer RS40 to fixate the parallell rail pieces at a correct distance from each other, depending on coil widthOne pc per 4 meters is needed for lenghts over 4 metersFor Rail RS40 and Rail RS40 Outdoor (WR)
Lankhorst Rail End Spacer RS40
252577
Used together (in pair) with Tunnel End spacer RS40 at the end of each rail section to fixate the parallell rails at a correct distance from each other, depending on coil width, and to protect the edges of the rail
2 pcs per linked rail section is needed (one in each end) regardless of section length
For Rail RS40 and Rail RS40 Outdoor (WR)
2 pcs per linked rail section is needed (one in each end) regardless of section length
For Rail RS40 and Rail RS40 Outdoor (WR)
Lankhorst Tunnel End Spacer RS40
252578
Used together (in pair) with Rail End spacer RS40at the end of each rail section to fixate the parallell rails at a correct distance from each other, depending on coil width, and to protect the edges of the rail
2 pcs per linked rail section is needed (one in each end) regardless of section length
For Rail RS40 and Rail RS40 Outdoor (WR)
2 pcs per linked rail section is needed (one in each end) regardless of section length
For Rail RS40 and Rail RS40 Outdoor (WR)
Lankhorst End Cap RS40
253132
For applications where spacers are not used, the rail needs to be fixated t the floor and protected using End caps
2 pcs per linked rail section is needed (one in each end) regardless of section length
For Rail RS40 and Rail RS40 Outdoor (WR)
2 pcs per linked rail section is needed (one in each end) regardless of section length
For Rail RS40 and Rail RS40 Outdoor (WR)
Lankhorst OilStop RS40
253289
For oily coils the OilStop can be used to collect the dripping oil and prevent the oil from staining the floor
For use on the RS40 systems
For use on the RS40 systems
Lankhorst Installation Tool RS40
252556
The installation Tool RS40 is used to tighten the Steel Connector RS40 when connecting rail lengths over 4 meters
The Installation Tool RS40 ensures that you get the correct space between connected rails RS40, to ensure the blocks (RollStop RS40, CoilWedge 120/34 or 150/34 or RollCradle) can also be placed over the joints
One to two Installations tools are needed for a complete system, depending on the size of the system and the number of people installing the system
The Installation Tool RS40 ensures that you get the correct space between connected rails RS40, to ensure the blocks (RollStop RS40, CoilWedge 120/34 or 150/34 or RollCradle) can also be placed over the joints
One to two Installations tools are needed for a complete system, depending on the size of the system and the number of people installing the system
Lankhorst RollStop RS100
252262
Diameter coils: 700-2500 mm
Coil width: 650-1950 mm (using spacers)
Max load (using 4 RollStops): 100 tons
Temperatures up to 60 °C
For stacking up to 3 levels
To be used together with Rail RS100 or Rail RS100 WR
Coil width: 650-1950 mm (using spacers)
Max load (using 4 RollStops): 100 tons
Temperatures up to 60 °C
For stacking up to 3 levels
To be used together with Rail RS100 or Rail RS100 WR
Lankhorst RollStop RS100 HR
252386
Heat resistant version, for temperatures up to 110°C
Diameter coils: 700-2500 mm
Coil width: 650-1950 mm (using spacers)
Max load (using 4 RollStops): 100 tons
Temperatures up to 60 °C
For stacking up to 3 levels
To be used together with Rail RS100 or Rail RS100 WR
Diameter coils: 700-2500 mm
Coil width: 650-1950 mm (using spacers)
Max load (using 4 RollStops): 100 tons
Temperatures up to 60 °C
For stacking up to 3 levels
To be used together with Rail RS100 or Rail RS100 WR
Lankhorst Rail RS100
252261
To be used togehter with the RollStop RS100 or CoilWedge 120/45 or 150/45
1 pc rail =4 meters
Always used in pairs of two
Also available in weather resistant version (Lankhorst Rail RS100 Outdoor (WR))
To create lengths over 4 meters, the Steel Connector RS100 must be used
1 pc rail =4 meters
Always used in pairs of two
Also available in weather resistant version (Lankhorst Rail RS100 Outdoor (WR))
To create lengths over 4 meters, the Steel Connector RS100 must be used
Lankhorst Rail RS100 Outdoor (WR)
252488
Weather resistant version for outdoor use
To be used togehter with the RollStop RS100 or CoilWedge 120/45 or 150/45
1 pc rail =4 meters
Always used in pairs of two
To create lengths over 4 meters, the Steel Connector RS100 Outdoor (WR) must be used
To be used togehter with the RollStop RS100 or CoilWedge 120/45 or 150/45
1 pc rail =4 meters
Always used in pairs of two
To create lengths over 4 meters, the Steel Connector RS100 Outdoor (WR) must be used
Lankhorst Steel Connector RS100
252350
Links the rail sections to create sections longer then 4 meters
To tighten the Steel Connector an Installation tool RS100 is needed
To tighten the Steel Connector an Installation tool RS100 is needed
